This type fixed scissor lift is Stationary Lift Platform which used to convey the goods from one working level to another.
The control panels are available at the designated floors and on the platforms.
Heavy capacity, platform size and lifting height can be chosen according your actual need.
hydraulic fixed Scissor Lift Platform features:f
Installed in the pit or directly on the ground.
When lifting up or down, there are up, down, stop three buttons control the lift.
Great load capacity,125%capacity load test. Non-slip platform is safe.
Sensitive overload protection devices locking device for failing protection.
Specification
Model | Platform size(MM) | Load capacity (KG ) | Lifting height (M ) | Outline drawing (MM) | Pump station (kw) |
SJG0.3-1.2 | 2350*1630 | 300 | 1.2 | 2350*1630*350 | 2.2 |
SJG0.5-2.5 | 1500*1500 | 500 | 2.5 | 1500*1500*480 | 2.2 |
SJG1.5-5.5 | 2000*2000 | 1500 | 5.5 | 2000*2000*970 | 3.0 |
SJG3-3.5 | 2000*3000 | 3000 | 3.5 | 2000*3000*800 | 4.0 |
SJG5-1.2 | 2600*2600 | 5000 | 1.2 | 2600*2600*530 | 4.0 |
SJG8-1.5 | 2500*2400 | 8000 | 1.5 | 2500*2400*550 | 5.5 |
SJG15-1.2 | 2500*2400 | 15000 | 1.2 | 2500*2400*650 | 7.5 |
Detailed information:
Advantage
(1) Hydraulic lifting system, the remote control and multi-control points at the different floors could be realized.
(2) Lift Up, Stop and Lower could be realized at each control point. The fixed Hydraulic Scissor lift could stop at the accurate location point.
(3) Smooth working condition, high load capacity, safe and reliable.
(4) There are optional sensitive overload protection devices and safety trip bar.
(5) Power Supply is from local power sources.
